| Application: |
Non-fatty and non-oily foods and liquids, potable water, sanitary products. Acids, chemicals, solvents, In-plant and tank transfer, delivery, transport |
| Inner Tube: |
Translucent ultra-high molecular weight polyethylene (UHMWPE) |
| Reinforcement: |
Multiple textile plies with dual wire helix |
| Outer Cover: |
Green EPDM; corrugated wrapped finish EPDM Water Discharge Hos |
| Temp. Range: |
-40°C to +121°C (-40°F to +250°F). |
| Hose I.D |
Hose O.D |
Working Pressure |
Minimum Bend Radius |
Approx. Weight |
| inch |
mm |
inch |
mm |
psi |
bar |
inch |
mm |
lbs/ft |
kg/m |
| 1 |
25.4 |
1.37 |
34.9 |
250 |
17.2 |
1.0 |
25.4 |
0.38 |
0.56 |
| 1-1/4 |
31.8 |
1.62 |
41.3 |
250 |
17.2 |
1.3 |
33.0 |
0.48 |
0.72 |
| 1-1/2 |
38.1 |
1.87 |
47.8 |
250 |
17.2 |
1.5 |
38.1 |
0.62 |
0.92 |
| 2 |
50.8 |
2.43 |
61.9 |
250 |
17.2 |
2.0 |
50.8 |
0.93 |
1.34 |
| 3 |
76.2 |
3.43 |
87.3 |
200 |
13.8 |
4.5 |
114.3 |
1.45 |
2.17 |
| 4 |
101.6 |
4.50 |
114.3 |
200 |
13.8 |
8.0 |
203.2 |
2.17 |
3.22 |
|
